72KW Custom Air Source Heat Pump with Titanium Heat Exchanger and Scroll Compressor

Product Categories
Foshan Meidebao Intelligent Electrical Appliances Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

72KW Custom Air Source Heat Pump with Titanium Heat Exchanger and Scroll Compressor

  • 1
  • 2

Brand Name : meidibao

Model Number : KFXRS-70II-M3

Place of Origin : China

MOQ : 1SET

Payment Terms : T/T

Price : negotiate a price

Supply Ability : 5 set one day

Delivery Time : 25-30 days

Packaging Details : wooden frame or plywood box

Certification : CE

Name : Custom Heat Pump

heat exchanger : Titanium

Cop : 3.8

Refrigerant : R410A

Power Supply : 380V/3PH/3wire /60Hz or 50Hz

Compressor Type : Scroll

Type : Air Source Heat Pump

Contact Now

72KW Non Standard R410A Heat Pump Customized 380V / 3PH / 3 Wire, Inner Threaded Tube
Meidibao air source heat pump system is powered by ambient air and operates around the clock, providing continuous hot water throughout the year regardless of weather conditions. The operating cost is 67% less than gas water heaters, 75% less than electric water heaters, and 60% less than boilers. Intelligent control: The unit is automatically controlled by a microcomputer and runs according to the water temperature of the tank and user's water usage, requiring no special duty personnel.
Key Features
  • Compressor: World-famous brand rotary type or fully enclosed vortex compressor with low noise, low vibration, high efficiency, and long service life. Multiple compressor units feature automatic unloading at partial load to save energy and prevent frequent starts.
  • Water Side Heat Exchanger: High-efficiency shell tube or threaded casing heat exchanger with small volume, light weight, easy disassembly, convective heat conduction, and maximum working pressure of 45kgf/cm². Insulated with 10mm PE to prevent energy loss.
  • Air Side Heat Exchanger: Integral hydrophilic finned inner threaded tube design with large windward area, high heat transfer efficiency, oxidation and corrosion resistance. Hydrophilic fins reduce condensation and frosting, ensuring reliable heating capacity in cold winter conditions.
  • Low Noise Fan: Domestic famous brand motor with axial impeller design, anti-aging blades, and strict static balance experiments for optimal fan efficiency and noise levels.
  • Housing Materials: External sheet metal made of galvanized steel with rust removal, cleaning, drying, and electrostatic spraying for beautiful appearance and durability.
Technical Specifications
Product Air Source Heat Pump
Model KFXRS-70II-M3
Climatic Type Normal
Power Supply 380V～/60Hz
Rated Heating Capacity 72kW
Rated Power Input 20kW
Max Rated Current 40A
Refrigerant / Charge R410/2600g×4
Rated Water Temperature 55℃
Max Hot Water Temperature 60℃
Working Temperature 0-43℃
Water Pipe Size DN50
Noise ≤78dB(A)
Product Dimension 2000×1250×1160mm
Net Weight 550kg
Advantages
Heat pump form heating: No need to build a boiler room, directly absorbs heat from the air, reducing costs while providing clean and safe operation that avoids environmental pollution. For locations with insufficient heat pump capacity in winter, auxiliary electric heating can be added to meet heat requirements. High efficiency, energy saving, reliable performance: Uses world-famous brand compressors and high-quality refrigeration components to ensure maximum energy efficiency. Multi-system units feature two-stage energy regulation, especially suitable for partial load conditions, providing additional energy savings and protecting against frequent system starts.
72KW Custom Air Source Heat Pump with Titanium Heat Exchanger and Scroll Compressor 72KW Custom Air Source Heat Pump with Titanium Heat Exchanger and Scroll Compressor
