18KW Ground Source Heat Pump with LCD Touch Panel Control and R410A Refrigerant for Efficient Hot Water Heating

Brand Name : meidibao

Model Number : M-D18WDH

Certification : CE

Place of Origin : China

MOQ : 10 units

Price : negotiate a price

Payment Terms : T/T

Supply Ability : 20 units one day

Delivery Time : 25-30 days

Packaging Details : Factory standard packing

heat exchanger : plate heat exchanger

Refrigerant : R410A

Power Supply : 230V/1P/50HZ

Type : water to water

Throttle Device : EEV

Control : LCD touch panel standard/internet ,APP control alternative

Name : Custom Heat Pump

Contact Now

DC Inverter Heat Pump 18KW Ground Source Heat Pump For Hot Water & Baseboard Heaters
Product Overview

The 18KW Custom Heat Pump inverter Ground Source Heat Pump is designed for efficient hot water production and space heating applications. This water-to-water heat pump can be applied in various settings including boiler/cooling tower configurations, geothermal closed or open loop applications, or hybrid systems.

Key Features
  • High COP: 5.10/5.25/5.20 (Rated working condition: heating: source side inlet/outlet water temp: 10℃/7℃, use side inlet/outlet water temp: 30℃/35℃)
  • Hot Water Temperature: 20℃ to 65℃
  • Power Supply: 380V/50Hz/3P, 220V/50Hz/1P
  • Source Side Temperature: -3℃ to 30℃
  • Heating Capacity: 5KW/12KW/18KW/24KW
Technical Specifications
Model M-D18WDH
Performance at W10/7℃, W30/35℃
Rated Heating Capacity kW 18
Heating Capacity Range kW 5.5-19.8
COP / 5.15
Rated Input Power kW 3.5
Performance at W0/-3℃, W30/35℃
Rated Heating Capacity kW 15.48
Heating Capacity Range kW 4.64-17.03
COP / 4.3
Rated Input Power kW 3.58
Functions / Hot water + Room heating/cooling + Solar control (Change over automatically)
Control / LCD touch panel standard / Internet, APP control alternative
Delivery Water ℃ 20-65℃
Power Supply / 380V/3P/50Hz
Noise dB(A) 40
Technology Advantages
  • Utilizes DC inverter technology and REPM compressor with adjustable running speeds
  • Automatically adjusts output capacity based on ambient or water temperature variations
  • Heats storage tanks and rooms faster than conventional on/off heat pumps
  • Provides precise temperature balancing for water and air
  • Delivers high COP as inverter system minimizes energy waste
  • Frequency changeable technology enables compressor speeds exceeding 5000rpm at -25℃ ambient temperatures
  • Increases refrigerant mass flow rate to offset source energy loss in cold climates
  • Maintains acceptable performance even in very cold climate conditions
Product Images
18KW Ground Source Heat Pump with LCD Touch Panel Control and R410A Refrigerant for Efficient Hot Water Heating 18KW Ground Source Heat Pump with LCD Touch Panel Control and R410A Refrigerant for Efficient Hot Water Heating 18KW Ground Source Heat Pump with LCD Touch Panel Control and R410A Refrigerant for Efficient Hot Water Heating
